TECNOLOGÍA
TUNED COMPLIANCE CONCEPT (TCC) ENDURANCE
Los modelos Roadmachine cuentan con el TCC Endurance, la versión más capaz de nuestra tecnología Tuned Compliance Concept, que elimina las incomodidades propias de las carreteras más complicadas, lo que te permite empujar más y rodar más lejos.
SILLÍN DE TIPO "D"
La nueva tija absorbente de tipo “D” se mantiene fija por un ingenioso sistema de anclaje integrado.
ABRAZADERA DE SILLÍN INTEGRADA
Abrazadera integrada, sin juntas y funcional
SOPORTE EN EL TUBO SUPERIOR
El tubo superior permite montar bolsas y accesorios atornillables.
ESPECIFICACIONES COMPLETAS
-
SPEC
SRAM FORCE eTap AXS
-
CUADRO
Roadmachine Premium Carbon with Tuned Complaince Concept Endurance
• ICS Technology, stealth cable routing
• TCC Endurance compliance level
• Internal Cable Routing
• PF86 bottom bracket
• 12x142mm thru-axle
-
HORQUILLA
Roadmachine 01 Premium Carbon with Tuned Complaince Concept Endurance
• ICS Technology
• TCC Endurance compliance level
• 12x100mm thru-axle
• 50mm offset (Size 47-51), 45mm offset (Size 54-61)
-
MARCHAS
2x12
-
PLATO
SRAM FORCE AXS 46/33T
-
CASSETTE
SRAM FORCE XG-1270, 10-36T
-
CADENA
SRAM FORCE 12 speed
-
DESVIADOR DELANTERO
SRAM FORCE eTap AXS
-
DESVIADOR TRASERO
SRAM FORCE eTap AXS
-
MANETAS CAMBIO
SRAM FORCE eTap AXS HRD
-
FRENOS
SRAM FORCE eTap AXS HRD, Centerline XR Rotors (160/160)
-
MANILLAR
BMC RAB 02, ergo top shape, compact bend
-
POTENCIA
BMC ICS 01 - Integrated Cockpit Design, w/ computer and camera mount
-
TIJA SILLÍN
01 Premium Carbon D-Shape Seatpost
• 15mm offset
-
SILLÍN
Fizik Taiga
-
BUJES
DT Swiss E 1800 SPLINE db 32
-
LLANTAS
DT Swiss E 1800 SPLINE db 32
-
NEUMÁTICOS
Vittoria Rubino, 28mm
-
PESO
8.3 KG
Material del Cuadro
Carbono
GEOMETRÍA
| TALLA |
47 |
51 |
56 |
58 |
61 |
54 |
| Rider Height CM |
<166 |
166-174 |
178-186 |
184-192 |
> 190 |
172-180 |
| Top Tube MM (tt) |
522 |
532 |
556 |
568 |
583 |
546 |
| Wheelbase MM (wb) |
982 |
999 |
1008 |
1020 |
1035 |
997 |
| Seat Angle (sa) |
74.2 |
74.2 |
74.2 |
74.2 |
74.2 |
74.2 |
| Seatpost Length MM |
331 |
381 |
381 |
381 |
431 |
381 |
| Stack MM |
516 |
541 |
586 |
610 |
644 |
562 |
| Trail MM (trail) |
63 |
63 |
63 |
63 |
63 |
63 |
| Reach MM (reach) |
374 |
382 |
390 |
394 |
398 |
386 |
| Head Tube MM (ht) |
112 |
139 |
181 |
206 |
242 |
N/A |
| Head Angle (ha) |
71.2 |
71.2 |
72 |
72 |
72 |
72 |
| BB Drop MM (drop) |
71 |
71 |
71 |
71 |
71 |
71 |
| Stem Length MM |
90 |
90 |
110 |
120 |
120 |
100 |
| Seat Tube MM (st) |
420 |
457 |
522 |
539 |
573 |
500 |
| Stem Angle |
-12.5 |
-12.5 |
-12.5 |
-12.5 |
-12.5 |
-12.5 |
| Crank Length MM |
170 |
170 |
172.5 |
175 |
175 |
172.5 |
| Fork Rake MM (fr) |
50 |
50 |
45 |
45 |
45 |
45 |
| Front Center MM (fc) |
583 |
597 |
609 |
621 |
635 |
597 |
| Fork Length MM (fl) |
375 |
375 |
375 |
375 |
375 |
375 |
| Bar Width MM |
400 |
420 |
420 |
440 |
440 |
420 |
| Bar Reach MM |
70 |
70 |
70 |
70 |
70 |
70 |
| Bar Drop MM |
125 |
125 |
125 |
125 |
125 |
125 |
