130-millimeters of suspension courtesy of a RockShox Judy Silver TK fork.
Highlights include SRAM Level hydraulic disc brakes and TranzX dropper post.
Wide-range SRAM SX 1X drivetrain provides crisp shifts and gearing to tackle any hill.
Frame
Specialized A1 Premium Aluminum, 148mm thru-axle, tapered head tube, internal cable routing
Seat Binder
Alloy, 38.6mm
Suspension
Fork
RockShox Judy Silver TK, air spring, 42mm offset, 130mm of travel
COCKPIT
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Stout Riser, double-butted alloy, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750mm / 780mm width, 31.8mm
Tape
Specialized Trail Grips
Saddle
Body Geometry Bridge Saddle, steel rails
SeatPost
TranzX Dropper, 30.9mm, XS-S: 100mm, M-XL: 120mm
BRAKES
Front Brake
SRAM Level, hydraulic disc, 180/160mm
Rear Brake
SRAM Level, 2-piston caliper, hydraulic disc, 180mm
DRIVETRAIN
Rear Derailleur
SRAM SX Eagle, 12-speed
Shift Levers
SRAM SX Eagle, trigger, 12-speed
Cassette
SRAM PG-1210 Eagle, 11-50t
Chain
SRAM, SX Eagle, 12-speed
Crankset
SRAM, SX Eagle, 12-speed Boost, Powespline, 32T
Bottom Bracket
SRAM Powerspline
WHEELS
Rims
Alloy, disc only, double-wall, 29mm internal width, 28h, tubeless compatible
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h
Front Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
Inner Tubes
Presta, 40mm valve
WHEELS & TIRES
Spokes
Stainless, 14g
* Pesos basados en cuadros pintados de producción como se muestra en la imagen. Los pesos reales variarán en función del color, tamaño del cuadro y variación de componentes. Las especificaciones están sujetas a cambios sin previo aviso.
XS |
S |
M |
L |
XL |
|
Largo de biela |
170mm |
170mm |
170mm |
170mm |
175mm |
Largo de poste de asiento |
360mm |
360mm |
400mm |
400mm |
400mm |
Ancho de manubrio |
750mm |
750mm |
780mm |
780mm |
780mm |
Largo de avance |
45mm |
45mm |
45mm |
45mm |
45mm |
Saddle Width |
155mm |
143mm |
143mm |
143mm |
143mm |
Stack |
603mm |
603mm |
603mm |
615mm |
630mm |
Alcance |
400mm |
420mm |
440mm |
460mm |
480mm |
Largo de tubo de dirección |
105mm |
105mm |
105mm |
120mm |
135mm |
Ángulo de tubo de dirección |
66° |
66° |
66° |
66° |
66° |
B-B Height |
315mm |
315mm |
315mm |
315mm |
315mm |
Caída de caja pedalera |
48mm |
48mm |
48mm |
48mm |
48mm |
Trail |
113mm |
113mm |
113mm |
113mm |
113mm |
Fork Length (full) |
520mm |
520mm |
520mm |
520mm |
520mm |
Fork Rake/Offset |
42mm |
42mm |
42mm |
42mm |
42mm |
Front-Center |
695mm |
715mm |
735mm |
761mm |
787mm |
Largo de vaina inferior |
430mm |
430mm |
430mm |
430mm |
430mm |
Distancia entre ejes |
1120mm |
1140mm |
1160mm |
1186mm |
1213mm |
Top-Tube Length (horizontal) |
573mm |
593mm |
613mm |
637mm |
661mm |
Bike Stand-Over Height |
717mm |
736mm |
739mm |
744mm |
789mm |
Seat-Tube Length |
340mm |
375mm |
410mm |
455mm |
505mm |
Ángulo de tubo de asiento |
74° |
74° |
74° |
74° |
74° |
