TECNOLOGÍA
ACCELERATED COMPOSITES EVOLUTION TECHNOLOGY + (ACE+)
ACE+ no solo crea miles de prototipos virtuales basándose en la rigidez, el peso y el cumplimiento como parámetros clave, sino que ahora incluye un cuarto factor clave en la creación de prototipos, la aerodinámica.
INTEGRATED COCKPIT SYSTEM (ICS) CARBON
El ICS Carbon es un cockpit de una sola pieza con un peso increíblemente bajo, una alta rigidez, un sigiloso guiado de los cables, y soportes integrados para montar los dispositivos más populares.
DISEÑO AEROCORE
Nuestro sistema Aerocore consta de dos portabidones superligeros de carbono que se integran perfectamente en los remodelados tubo diagonal y tubo de sillín, lo que reduce significativamente la resistencia aerodinámica cuando se usa con bidones.
TIJA DE SILLIN DE TIPO "D"
La última evolución de nuestra emblemática tija de sillín de tipo “D”: este diseño optimizado cuenta con una abrazadera de sillín minimalista, lo que reduce el peso, al tiempo que asegura un excelente rendimiento aerodinámico y cumplimiento.
ESPECIFICACIONES COMPLETAS
Cuadro
Cuadro:
Teammachine SLR 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | TCC Race Compliance Level | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Horquilla:
Teammachine SLR 01 Premium Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Cockpit
Manillar:
ICS Carbon - One-Piece Full Carbon Cockpit
Tija de Sillín:
Teammachine SLR 01 Premium Carbon D-Shaped Seatpost |
Sillín:
Antares Versus 00 Adaptive
Transmisión
Marchas:
2x12
Platos y Bielas:
Campagnolo Super Record 52-36T
Cassette:
Campagnolo Super Record 11-29 12s
Cadena:
Campagnolo Super Record 12s
Desviador Delantero:
Campagnolo Super Record EPS
Cambio Trasero:
Campagnolo Super Record EPS 12s
Manetas de Cambio:
Campagnolo Super Record EPS
Frenos
Pinzas de Freno:
Campagnolo Super Record
Discos:
Campagnolo 03 AFS160 / 140mm
Ruedas
Llantas:
Campagnolo Bora Ultra WTO 33 Disc 2-Way Fit - 33mm (Tubeless)
Bujes:
Campagnolo Bora Ultra
Neumáticos:
Pirelli P ZERO RACE TLR SL - 26mm (Tubeless)
Información Tubeless:
Tubeless Ready Rims / Tubeless Tires
Accesorios
Información adicional
Anchura Máx. de Neumático:
30mm (Measured Width)
Clasificación ASTM:
Level 1
Límite de Peso:
110 Kg
GEOMETRÍA
| Size | 47 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
| Reach | 367 | 377 | 386 | 392 | 401 | 409 |
| Stack | 506 | 530 | 550 | 565 | 584 | 608 |
| Bar Drop | 127 | 127 | 127 | 127 | 127 | 127 |
| Bar Reach | 67 | 67 | 67 | 67 | 67 | 67 |
| Bar Width | 400 | 420 | 420 | 420 | 420 | 420 |
| BB Drop | 69 | 69 | 69 | 69 | 69 | 69 |
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Fork Length | 368 | 368 | 368 | 368 | 368 | 368 |
| Fork Rake | 48 | 48 | 43 | 43 | 43 | 43 |
| Front Center | 568 | 586 | 589 | 599 | 614 | 630 |
| Head Tube | 110 | 130 | 145 | 165 | 184 | 210 |
| Head Tube Angle | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
| Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
| Seat Angle | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Seat Tube | 423 | 468 | 504 | 524 | 545 | 574 |
| Seatpost Length | 330 | 380 | 380 | 380 | 380 | 380 |
| Seatpost Offset | 15 | 15 | 15 | 15 | 15 | 15 |
| Standover Height | 717 | 752 | 779 | 797 | 817 | 843 |
| Stem Angle | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 | -12.5 |
| Stem Length | 90 | 100 | 100 | 110 | 110 | 120 |
| Top Tube | 517 | 534 | 549 | 559 | 574 | 589 |
| Trail | 63 | 63 | 63 | 63 | 63 | 63 |
| Wheelbase | 968 | 986 | 989 | 1000 | 1015 | 1030 |
